Key Features
- •Chassis: Molded plastic, split line monocoque style molded style, gray in color, incorporates front and rear shock towers, gearbox, motor mount and upper suspension mounts, mid motor chassis design protects motor from dirt and water
- Drive: Rear wheel
- Transmission: Molded composite gears
- Differential: Ball bearing equipped, straight cut metal gears, diff lubed with grease, manufacturer does not specify viscosity
- Spur Gear: 48 pitch 93 tooth plastic
- Pinion Gear: 48 pitch 19 tooth metal
- Suspension: Double wishbone front and rear with captured hinge pins
- Radio: Arrma ATX-101 with dual rate steering, throttle end points throttle and steering trims
- Steering Servo: ADS-5 waterproof case, 70oz/in (5kg-cm) of torque, 25T spline
- Motor: Brush equipped, 540 size 20 turn, three motor mounting positions to allow the use of three pinion sizes
- Electronic Speed Control: 3-in-1 SRS combines ESC, receiver and electronic control for the servo (standard 3-wire servo can also be plugged into the unit if driver wants to use a different servo) SRS unit is compatible with 2S LiPo, 2-6 cell Li-Ion, & 6-cell NiMH batteries, battery types switchable with jumper, 2-stage low- voltage cutoff for LiPo, Li-Ion, and single stage cutoff for NiMH batteries
- Shocks: Oil-filled at factory with 350cst mineral oil, equivalent to around 30wt shock oil from other manufacturers
- Steering: Fixed links with servo saver
- Battery: Two INR18650P button top Li-Ion cells are included, up to six Li-Ion cells can be used for longer run times.
- Battery Charger: 110V wall type
- Battery Tray: Holds up to six Li-Ion 18650 cells, 2S LiPo pack or 6-cell NiMH stick pack, side loading design-battery is held in place by pivoting door on chassis-no pins or clips to lose, integrated T-plug provides connection to SRS unit when using lithium ion cells, maximum battery dimensions are 5.55 x 1.89 x 1.02" (141 x 48 x 26mm)
- Body: Trimmed and printed
- Wheels: Multi spoke, nylon construction, black in color, 2.2" (56mm) bead diameter, 12mm hex
- Tires: dBoots Dirtrunner ST ribbed front, treaded rear 2.2" (56mm) wide, 4.33" (110mm) diameter
- Caster: Non-adjustable caster/toe-in refers to the angle of the front suspension when viewed from the side of the car in relation to the chassis
- Camber: Non-Adjustable, camber refers to the angle of the tops of the tires from vertical when viewed from front or behind vehicle
DESIGNED FAST DESIGNED TOUGHARMA is a label, which defines the high speed-RC-action new.Here starts your journey into the fantastic world of the RC-car-driving because ARRMA offers exciting vehicles for every purpose.It doesn't matter, if you are a newcomer in the RC-car-hobby or if you are an old hand, ARRMA has everything to present newcomer and experts with a challenge.Designed by experts, who unterstand their business, offer the ARRMA-vehicles a preeminant cost effectiveness, excellent speed and a robust construction, because ARRMA-vehicles are "Designed to be Fast, Designed to be Touch".
