S1031.77

The Graupner remote control mc-28 HoTT is a console transmitter for the advanced model sportsman. The mc-28 is suitable for almost all models and offers features that are also suitable for functional model builders on land and on water. 16 control functions, 120 internal model memories, integrated telemetry and voice output, as well as the fast and secure bi-directional transmission of Graupner HoTT 2.4 GHz technology, make the mc-28 a true all-rounder. The mc-28 remote control has an internal circular polarized patch antenna with very high range and reliability. Likewise, the digital and temperature-calibrated Hall sensor stick units have excellent durability, reliability and precision. Two large, high-contrast displays provide information on telemetry data and parameters at all times and allow quick and easy programming.The switches and buttons of the remote control can be freely assigned and thus individually adapted. 12 mixers are available for programming. 8 switching phase programs with announcement function can be adapted and named for each model.Thanks to the micro-SD card and micro USB interface, telemetry data and model memory can be imported and exported. Upgrades of the computer system are also carried out easily.8 switching phase programs can be individually adapted and named for each model, the switching time can be programmed separately. Functional model builders can use the phases to switch function groups. e.g. on an excavator, in one phase the driving functions are controlled by the sticks and after switching, the sticks are available for the body functions.3 ring limiters for Voith-Schneider or Schottel drives and similar. The ring limiter avoids oversteering of the drives at certain stick positions to avoid damage to the VSP or to ensure a homogeneous speed of the propeller in the Schottel drive when using our Schottel control 1762 in combination with a brushless motor.Multi-channel function: For switching up to 16 additional functions or up to 8 additional servos, two of the classic multiswitch decoders or multipropdecoders are integrated in the software. For control, all available switches or encoders can be used and up to 4 additional switches can be retrofitted with the corresponding adapter cables for UVR switches 33000.16/-17. The multichannels can be controlled by our sound modules 2386.F and 2386.S, the light module 2381, the Nautic-Expert switching module 4159, 16 channel switching module 3972 and the 4 channel proportional module 3973.General features:- Microcomputer remote control system in latest 2.4 GHz Graupner HoTT technology- circular polarized patch antenna- Temperature calibrated billet aggregates in the double ball bearing aluminium billet aggregates- Vibrating alarms- Charging via MicroUSB with LED charge indicator- Model types: flight model, helicopter, copter, vehicle, boat- Voice output by switch operation or switching phase change with a choice of over 400 voice outputs and up to 40 user-definable voice outputs- Up to 10 user-definable alerts- 10 different vibration alarms for telemetry alerts, timer, RF signal, voltage alarm- Return channel speed for towing or camera helicopter with several transmitters and receivers adjustable in the model- Music player via programmable start/stop switch- Bidirectional communication between sender and receiver- Wireless L/S function- different languages (German, English, French, Italian, Spanish) possible via software update For availability of the corresponding language see download area.- Storage of telemetry data with date and time- Servo cycle times for digital servos of 10ms selectable.- Ultra-fast response times due to direct and reliable data transmission from the main processor to the 2.4 GHz transceiver. No additional delays due to detours via a module processor.- Operation and programming based on the proven concepts of the mc-32- A high-contrast blue illuminated graphic display guarantees perfect control of the setting parameters such as model type, model memory, clocks and operating voltage.- 16 control functions- Free assignment of all switches- 120 model memories- 10 switches/buttons, of which two 3-step switches long, four 2-step switches, 2 buttons long, 2 buttons on the back and 2 sliders and 2 lateral rotary encoders- Mode 1 to 4 freely selectable- CAP-TOUCH control panels with key-lock function against unintentional operation.- Numerous telemetry, programming and evaluation functions directly in the transmitter display- Voice output can be called up via freely programmable switches- Extensive programs for wing and helicopter models- Swashplate limiter- Switch "Monitor" for control of all switches and encoder switches- 12 mixers, freely programmable for wing models and helicopters, each with freely selectable input and output functions, 4 of them curve mixers with 5-point curve technology in 1% steps, thus easily set and adjustable curve values for max. 5 points for throttle, pitch, tail or other non-linear travel. The CPU calculates a real rounded ideal MPC (Multi-Point-Curve) mixer curve with a sophisticated polynomial approximation method.- 8 switching phase programs with announcement function can be individually adapted and named for each model, the switching time can be programmed separately.- SUPER-SERVO menu with perfect overview of all servo setting data and simple parameter correction for 4 levels (direction of rotation, center position, servo travel separated on both sides and travel limitation separated on both sides for 16 servos with a total of 96 setting options)- SUPER-DUAL-RATE, EXPO menu with 36 possible setting variants, for 3 servo functions and 6 flight phases.- Practice-optimized multi-function menus for wing and helicopter models. Entering the number of aileron and flap servos automatically programs all necessary mixer functions in the multi-function wing menu. Differential aileron mixer, butterfly mixer, dual flap mixer, automatic gyro set function and other special functions- Helicopter swashplate mixer for 1-, 2-, 3- or 4-point linkage.- Fail-safe monitor for 16 servo functions- Comfortable clock menu . Stopwatch system, alarm timer, countdown timer, lap counter etc. 2 time and 1 lap/time value can be displayed.- Stopwatch with history : In addition to the lap counter there is a time 1 which records the switch-on times and a time 2 which records the ON and OFF switch-on times separately.- Transmitter operating time timer is automatically set to zero by the battery charging process of the transmitter.- Switch assignment of the flight phase switches: Now 6 switches, 2 of them with priority function . The designation of each switch combination is freely selectable. Thus the number of flight phases is independent from the number of flight phase switches.Maximum safety- Extremely high range: 3000m (down or forward > 1000m)- FHSS, frequency hopping over up to 75 channels- Maximum noise immunity through optimized frequency hopping, wide channel spreading and antenna diversification- Intelligent data transmission with correction function- Range test and warning function- Low voltage warning- Numerous fail-safe functions- Key-Lock function to prevent unintentional menu changesHighest precision- Shorter reaction times can be set (10ms period time)- No additional delays caused by module processors. All hopping management is performed directly by the 32-bit main processor.- Synchronous servo run possible by simultaneous control of the servo outputs in blocks of 4 Unique pilot feeling- Largely delay-free control reactions through direct processing- Telemetry evaluation in real time- Optional voice output of clocks, telemetry data and warnings via headphone output- Repeat function and further function of the voice output programmable via freely assignable switches- Preselection of the language output to be output- Separately adjustable volume for beeps and voice output- Integrated telemetry display with 8 x 21 characters or 128 x 64 dots, optionally in text or graphic form- Display illumination duration: ALWAYS, 30s, .60s, 90s, 120s- Micro-SD card slot for storing telemetry data similar to a black box and for expanding the model memory- PC software for evaluation or display of telemetry data via download- Sum signal at the highest receiver output programmable for L/S function, satellite receiver, simulators, paddleless rod systems etc.- Binding dependent on model memory, except for copied model memories- Wireless teacher/student function- 3 flight phases programmable- Swashplate limiter- Motor off function- Numerous surface model and helimic mixersOther features- Simple and extremely fast binding- Free channel assignment (channel mapping), transmitter and receiver mixing functions and all servo settings easily programmable- Binding of any number of receivers for channel expansion (max. 16 channels). The last bound receiver sends the telemetry data.- Future-proof through update capability via PC interface 33028.77

Features:HoTT (HOPPING TELEMETRY TRANSMISSION) bi-directional 2.4GHz technology75 jump frequencies for safe transmission9 channels3.5" TFT colour touch display for easy operationIntelligent speech output of telemetry data, warnings, alarms and Vario signal via loudspeakers or headphonesReal-time data transmission with optional sensors (Vario, GPS, fuel, temperature, voltage, current, speed and much more)Teacher/student system wireless or wiredBinding of several receivers possibleBall bearing billet units (total 8 units)µSD card slot for model memory expansion and telemetry data recording30 model memoriesModel copy functionUpdateable via USBModel type: helicopter, flight model (normal or delta), glider modelNumerous servo settings (travel, limit, reverse, center position)DualRate and Expo, separately adjustable for each flight phase6 flight phasesHelicopter type: 1 servo, 2 servo 180°, 3 servo 120° (2 pitch or 2 roll), 3 servo 140°, 4 servo 90°Pitch curves (7 points) separately adjustable for each flight phaseGas curves (7 points) separately adjustable for each flight phasePhase trims for pitch and gasSwash plate limiter functionSwash plate mixing function5 Linear mixer3 curve mixerNumerous model aircraft types from 1QR to 4-flap surfacesElevator: 1 HR, 2HR, V-tailSnaproll functionAileron differentiation, separately adjustable for each flight phaseButterfly functionNEW:Security:FHSS, frequency hopping over up to 75 channelsMaximum noise immunity through optimized frequency hopping, wide channel spread and antenna diversificationIntelligent data transmission with correction functionExtremely high rangeRange test and warning functionlow-voltage warningExtremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)Numerous fail-safe functionsKeylog function to prevent unintentional menu changesPrecision:Shorter response times adjustable (10ms period time)No additional delays due to module processors. All hopping management is done directly from the 32-bit main processor.Synchronous servo run possible by simultaneous control of the servo outputs in blocks of 4Pilot feeling:Largely instantaneous control reactions through direct processingTelemetry evaluation in real timeWireless teacher/student functionMore characteristics:Simple and extremely fast bindingFree channel assignment (channel mapping), transmitter and receiver mixing functions and all servo settings can be easily programmedBinding of any number of receivers for channel expansion (max. 16 channels). The last bound receiver sends the telemetry data.Future-proof due to update capability via USB interface S1005.77

All in oneThe Graupner mz-16 provides the technology and features only seen in high-end radios available as a 16 channel 2.4GHz HoTT radio. The mz-16 provides the pilot with a radio system where accuracy, control and reliability is fully integrated inside a high-tech carbon look and comfortable ergonomics transmitter.You are in controlThe mz-16 brings the same powerful features as our mz-32 radio introducing a new level of functionality where you, the user, can control almost any part of the radio. The mz-16 brings you the power to design your own screens, program your own control logic, filter your own voice notifications and even design the looks of your radio with removable colored face plates.Fly smoother with the mz-16The Graupner mz-16 provides 16 channel proportional functions and supports five different model types such as electric, gas or turbine airplanes, helicopters, multirotor, cars and even boats.It can store and load up to 999 different user models, has 8 flight-phases and 12 curve mixers which can be set global or flight-phase dependent! The machined aluminum quad bearing gimbals provide the smoothest control feel a pilot can experience which can be comfortably adjusted the way you like from the back of the radio.The mz-16 has a rock solid HoTT 2.4GHz RF system combined with a adjustable linear antenna for unmatched signal quality and extended range. The mz-16 adapts to youThe outdoor friendly 4.3-inch state of the art TFT color touchscreen ensures convenient access to all the mz-16 functions for setting up and managing your models. The highly optimized and fast performing graphical user interface is driven by a high-performance processor making access to menus and functions fast and crisp just like on your Smartphone. The intuitive touch and tap control make navigation around the menus fast, easy and fun! The mz-16 is not only fast and responsive but is also fast to load. You will be using your mz-16 from power up in no time! Designing your own screen layouts to display information or create menu shortcuts can be done on the fly by simply tapping on the screen. The mz-16 provides over hundred widgets which make up the screens that you like and fit your style for controlling your models. You can create in total six screens that better fit your needs and personal style using the tip of your finger. No programming needed! You can do it all with the mz-16! One radio for all! English, German, French, Dutch, Italian, Portuguese, Chinese, Korean, Spanish language is supported with more languages to come all in one radio!16 proportional channels and 16 digital switchesWith 16 channels the mz-16 provides unlimited functionality and control over any model that you have. You can bind two 2.4GHz receivers so you can layout and distribute the channels the way you want. For example, you can have one receiver that controls all your wing servos such as ailerons, flaps, landing gear, and lights. Just supply main power to the wing, and you are ready to go. No complicated wiring or expensive hubs needed! This provides you with a level of simplicity with the benefits of additional RF redundancy for extra peace of mind.Still need more channels but do not have enough switches to do what you want? The mz-16 also provides up to 16 digital switches that can be assigned and controlled with a single tap from the widget menu. Create as many digital switch combinations as you like for turning lights and smoke on or off, turn cranes or water guns or anything else that you need to control without using up your switches. Switching and control options are further enhanced with Logical Switches (And, Or, Equal, Not), Control Switches, Sensor Switches and Combination Switches. Each provides a new level of control to you depending on switch position, stick location or telemetry data.Voices you want to hearNeed to hear what is going on? The mz-16 provides endless options to generate almost any type of system or telemetry voice notification depending on the state of your radio such as switch positions, flight phase names, warnings, vario information and endless others. The mz-16 starts communicating with you from the moment you turn it on, informing you if a switch or control is in the wrong position for the selected model. No more surprises from collapsing landing gear, runaway motors or wrong gyro settings. The mz-16 can inform you when needed even when you forgot to bring down your landing gear or are about to run out of range or battery. Walks of shame are now a thing of the past! With over 600 installed voices and unlimited voice combinations, you can make almost any voice announcements or add as many as you want using our text to speech editor.Instant help where you need itIn need of help during setup or when something is unclear? Forget about searching through lengthy manuals or endless web searches! The mz-16 provides support right where you need it. Each menu and option have its own context-sensitive answers right on the screen. Just tap the question mark and you will be instantly presented with help and assistance. Don’t like our help screens? Make or add your own help screens with whatever content makes sense to you. The mz-16 is there for you allowing you to do and have the things you like the most.Connectivity that takes you furtherWith integrated WLAN the mz-16 is ready to connect you with the rest of the world!Connect to your wireless LAN to receive notifications about newly released firmware which are instantly downloaded and installed on your radio. Your mz-16 is always up to date with the latest and greatest! Updates can also be done with the included USB cable and our firmware upgrade studio software.Graupner takes connectivity further with a micro USB port that can charge your radio, access your included 16GB micro SD memory card where screens, models, voice files, music and screen shots can be stored.You can use the USB or DSC port also as a joystick controller for games and flight simulators. Now you can practice flying your model on your favorite flight simulator with the same radio that you use at the field! The data port on the back can be configured to output a variety of digital signal outputs like SUMD, CROSSFIRE, Smart Box, and more. Adding and using third-party modules such as long-range FPV has never been easier than with the mz-16. All Graupner HoTT receivers now also support digital serial wire output such as PPM, SUMD, and SBUS for more connectivity and better interoperability with third party flight controllers. Supported ProtocolsHOTT-PC - Smart-Box - External Monitor - SUMD - DSMX/DSM2 (Data Output) - CROSSFIREWireless ober the air setupComputers, wirers, and programming boxes are things of the past! The mz-16 HoTT wireless protocol lets you do everything right on the radio! Need to set up your telemetry, flight controller or reverse the direction of your ESC? Just use the shortcut key on the radio to access any of the connected devices, and you are immediately in business.Do this at home while setting up your model or at the field to fine-tune your settings. Enjoy the HoTT integration of third-party flight controllers and sensors like Ikon, Spirit, 3Digi, MSH-Brain, SM-Modelbau and many more for easy access using your mz-16 radio. Train your buddiesTraining your family members or friends is as easy as bind and teach! The mz-16 provides a wireless as well as wired trainer support you can use with other brand radios using the DSC port in the back. You can assign control to any of the active channels depending on your student's level and model capabilities. Passing control is easily done with a flick of a switch.HARDWARE“ Machined Aluminium Quad bearing gimbals for smooth and precise control“ Outdoor friendly 4.3-inch TFT color and touch screen“ Circular polarized patch antenna with adjustable beam angle“ 4000 mAh LiPo rechargeable battery for up to 4 hours of operation“ Micro-USB port for charging, data communication, joystick function or mass storage“ Externally adjustable stick tension and mode selection“ Internal µSD 16 Gb memory card“ Built in Wireless communication“ DSC socket for external communications (wired buddy box, flight simulators, other)“ Wireless student teacher operation“ Wireless firmware update“ Integrated speaker for voice output and telemetry notifications“ User configurable DSC and data ports (SUMD, CROSSFIRE and others)“ User assignable haptic feedback“ 5 x 3 position switches, 2 x 3 position/toggle switches, 1 x 2 position switch, 4 proportional knobs, “ 2 x lever controls, 8 assignable digital buttons“ 6 shortcut control and navigation keysSOFTWARE“ 16 proportional channels“ 999 Model memory“ 2 Receiver binding 10ms or 20ms frame rate“ Model, group or global binding modes“ Model types: Airplane, Helicopter, Multirotor, Vehicle, Boat“ 8 selectable flight modes“ 8 wing types, 6 delta wing types (total 14), 3 tail types“ Multi engine control (4)“ 6 user designable widgets dashboards (model specific or global)“ Context sensitive help text“ Airplane auto trim mode“ Text to speech with VDF editor“ Servo balancer & synchronization“ 5 phase dependent assignable trim settings and 5 trim types“ 4 phase dependent configurable timers (Start/Stop, Lap, Lap Trigger, Lap Toggle)“ 4 phase dependent quad rate and expo settings“ 12 phase dependent multi point user mixers“ 4 dual differential cross mixers“ 3 channel sequencers“ 3 channel ring limiters“ 16 user assignable digital switches“ 6 assignable combination switches“ 8 assignable logical switches“ 8 assignable control switches“ 4 snap roll mixes“ 8 wing and tail mixers and crow/butterfly function“ 9 user assignable and configurable system voice notifications“ 8 user assignable and configurable user voice notifications“ 12 user assignable and configurable control voice notifications“ 8 Sensor activated switches“ 8 User assignable and configurable voice notifications“ 4 Direct adjust control“ Dedicated vario and control menu with dead zone control“ Wireless setup of receivers, telemetry and flight controllers“ User configurable MP3 player“ Integrated file manager S1047.77

The Graupner mz-12 PRO is raising the bar for any radio in its price range. With 12 channels, 250 model memories, 5 model types, real-time voice telemetry, user announcements and 1500 mAh LiPo battery the mz-12 PRO is setting a new standard in value and performance!Easy to hold easy to useHolding the mz-12 PRO gives an instant locked feeling to the pilot. FPV and hand launch sailplane pilots will appreciate the design of the mz-12 PRO which provides better grip and accessibility to switches and controls. The included 1500mAh LiPo battery can be easily charged with the included micro USB cable.The mz-12 PRO micro USB port can be used for charging, software updates and for use as a joystick controller with supported games such as flight simulators. Now you can use the same model indoors for training purposes and outdoors to show off your new skills!Updating the mz-12 PRO with new software, user made voice notifications or user models is done with the free firmware update studio providing the user with additional flexibility and increased value.250 model memoriesNo need for storing models on SD cards or computers. With 250 model memories the mz-12 PRO provides you with almost unlimited storage for all your models. Moving models between your mz-12 PRO and computer is done with the firmware update studio where users can also share their models between their mz-12 PRO radioReal-time telemetryReal-time telemetry is already integrated in the mz-12 PRO and does not require any additional hardware for functions such as signal quality, temperature, or receiver voltage. The included Falcon 12 6-channel receiver provides telemetry functions that can be configured to notify you regarding any system changes. Graupner provides a wide selection of telemetry ESCs, modules and sensors that can immediately connect to and of our HoTT receivers and flight controllers without the need for external hub boxes or complex wiring.Add situational awareness and extra safety by easily assigning switches to telemetry functions and notifications to provide information about battery voltage, battery capacity, altitude, flight direction, speed, etc. The real-time, bi-directional HoTT transmission protocol will constantly monitor system health and notify you of any changes to the system. No more surprise situations such as sudden battery depletion or accidentally flying out-of-range!Programmable voice alertsConfigure any switch or control on the mz-12 PRO with a wide selection of voice announcements and alerts. Set up countless announcement combination options based on your needs and model conditions with flight-dependent voice triggers. Record your own voice messages to customize your experience by downloading the free Graupner Firmware Update Studio Program!The built-in speaker provides a loud and clear adjustable volume for all the radio notifications. Subsequently user can also use a headset for hearing notifications.FPV is kingThe mz-12 PRO is empowering multirotor pilots with features such as CROSSFIRE V2, race timers, telemetry and more. The included Falcon 12 receiver can be used as multirotor flight controller supporting a variety of ESC modes and multirotor configurations.Wireless setupNeed to reverse your motor direction, setup your Falcon flight controller or make telemetry settings? With the mz-12 PRO radio all these tasks can be easily done using the radio without the need for cables, computers or programming boxes! Just make all your settings changes on the fly at your shop or at the field!Five model typesAirplanes, helicopters, multirotors, boats, cars... the mz-12 PRO supports all model types! Setting up a helicopter or full house glider is easily done by simply selecting the right model type. For example, in airplane mode you can select from 4 tail types 5 wing types, 2 flight modes, 9 free mixers and 8 wing mixers.Each switch and control can be freely assigned to any channel based on preferences giving you the ultimate freedom to setup your model.Features:12 radio channels and 250 model memoriesQuad bearings gimbals for smooth operationIntegrated long range antennaMicrocomputer radio 2.4 GHz radio utilizing Graupner HoTT technologyUse of up to 75 frequency-hopping channels to ensure operating reliabilityRemoveable 1500mAh LiPo rechargeable batteryBattery charging indicator when charged with included USB cableBidirectional communication between transmitter and receiverFast 10ms frame rates when used with digital servosWireless or wired Teacher/Student link (buddy boxing)Micro USB Joystick function for flight simulator trainingModel types: Airplane, Helicopter, Multirotor, Boat and CarSupports 5 different languages (German, English, French, Italian and Spanish)Model memories can be stored and retrieved from computerIntuitive operation and programming‹ HoTTSync for exclusive and safe model operation Airplane Wing Types: 1AI, 1AI-1FL, 2AI, 2AI-1FL, 2AI-2FLAll switches and controls are user assignableRadio Switches: 2 x 3-position switches, 1 x 2 position spring loaded switch, 2 x 2 position switch, 1 analog rotary knobMode 1 to 4 freely selectableKey-lock function against unintended operation.2 programmable flight phasesHelicopter Swash plate limiterDual Rate and Expo individually adjustable and switchable during the flightWing mixers (aileron/flaps differential), (aileron rudder/flaps mixer), (elevator flap/aileron mixer), (flap elevator/aileron mixer)Multi point throttle curve in all model modesFree assignable mixers functions (5 linear mixers and 4 curve mixers)Programmable fail-safe function "Hold" or "Move to preset positions" can be set separately for each individual servo channelStopwatches / Countdown timer with alarm functionModel copy function for model memorySupported data formats on the DSC port: Telemetry, Bluetooth, CROSSFIRE V2 unidirectional S1002.PRO.77

Features:Machined-Aluminum quad bearing 4096 resolutions gimbalsExternal accessible stick tension adjustmentsReal-time SD-card data logging of critical flight informationBalanced weight distribution of radio with comfortable rubber hand gripsExternal DSC port for flight simulator connections or third party devicesExternal data port for optional Bluetooth5000 mAh LiPo batteryUpdateable firmware with Graupner Firmware Update StudioSoftware:Easy-to-use graphical programming menus3.5-inch thin-film transistor (TFT) color and touch screen12 programmable proportional channelsSupports all model types: airplanes, sailplanes, helicopters, multirotor, cars and boatsFlight phase assignable and programmable voice switchesUser created and user assignable voice filesReal-time telemetry voice announcements and alertsUser assignable switches and proportional controlsIn-flight auto trim of airplanes14 wing types for airplanes and sailplanesReady to go wing and flap mixers8 programmable mixers, 5 linear and 3 curve mixersWide range of sailplane programming: butterfly, camber, aileron differentialWireless student and teacher mode10 logical switch assignments3 channel servo sequencerDual, triple rates and exposAdjustable trim steps 0 to 10Selectable frame rates of 10ms or 20ms6 flight modes with voice announcementsMulti receiver binding for expansion and system redundancyUser adjustable mode selection (1, 2, 3 or 4)MP3 player (uses SD card up to 32 GB)HoTTSync for exclusive and safe model operationUse of up to 75 frequency hopping channels to ensure operating reliability30 model memories with almost unlimited model storage on SD memory cardSupport for digital SUMD, SBUS or SUMO (PPM) outputs for third party controllersSee it, hear it, touch itBright colors, voice announcements and a TFT touch screen is what makes the Graupner mz-24 PRO one of the most versatile radios on the market, and at a price that cannot be beat! Experience a new level of connection between you and your model with 12 channels and built-in real-time voice telemetry. Colorful menus and displays make usability easy to navigate through the menus and setup options with the touch of your finger or a stylus. Traditional navigation keys provide an old-school experience if you prefer to push physical buttons.The aluminum quad bearing 4096 resolution gimbals were machined with high-precision and are adjustable for smooth and accurate flight control. Safe and worry-free flights are achieved with our HoTT (Hopping Telemetry Transmission) technology by hopping over 75 2.4 GHz channels to secure the most reliable, interference-free operating channel. The red highlights adds a beautiful splash of color around the control sticks adding style to your gear.Real-time telemetryReal-time telemetry is integrated in all our HoTT radio systems. The mz-24 PRO does not require any additional hardware for functions such as signal quality, temperature, or receiver voltage. The included 8-channel and 6-channel receivers provide telemetry functions that can be configured to notify you regarding any system changes. Graupner provides a wide selection of telemetry ESCs, modules and sensors that can immediately connect directly to your HoTT receivers without the need for external hub boxes or complex wiring. Our third-party partners provide additional telemetry products that work seamlessly with your mz-24 PRO HoTT radio.Add situational awareness and extra safety by easily assigning switches to telemetry functions and notifications to provide information about battery voltage, battery capacity, altitude, flight direction, speed, etc. The real-time, bi-directional HoTT transmission protocol will constantly monitor system health and notify you of any changes to the system. No more surprise situations such as sudden battery depletion or accidentally flying out-of-range! During flight, important data is logged on the SD memory card which can be analyzed to improve your system's reliability and performance.Programmable voice alertsConfigure any switch or control on the mz-24 PRO with a wide selection of voice announcements. Set up countless announcement combination options based on your flying needs and airplane conditions with flight-dependent voice triggers. Record your own messages to customize your experience by downloading the free Graupner Firmware Update Studio Program!Logical switchesControl your model in every conceivable condition with logical switch positions or controls, adding a new dimension of control to the way we fly our models. For example, set up a logical switch that will not allow your gear to come down unless you have your flaps in the landing position. The AND/OR switch combinations are limited only by your imagination.Servo sequencerSet and save a series of up to nine timed events with the three-channel servo sequencer. With the flip of a trigger switch you can retract landing gears, open/close gear doors and have your pilot turn and wave to your adoring fans.Auto trim and stepIt's easy to trim your airplane, especially during its first flight! Just fly your airplane at level attitude and trigger the auto trim switch. The mz-24 PRO will automatically set the trims on your airplane. Freely assign the auto trim function to any switch for maximum flexibility during flight. The mz-24 PRO provides additional options for controlling trim settings, resulting in a perfectly trimmed model. Wireless setupNeed to reverse your motor direction, setup your flight controller or make receiver settings? The mz-24 PRO radio can easily setup, program, and change all Graupner HoTT products remotely, eliminating the need for cables, computers or programming boxes!Six model typesAirplanes, sailplanes, helicopters, multirotors, boats, cars...the mz-24 PRO supports all model types! Each has been specially programmed with different menu function specifications unique to that particular model. Further enhance the model with assigned voice triggers using specially uploaded (or custom tailored) files. S1006.PRO.77

The Graupner mz-10 remote control is a inexpensive and yet very reliable remote control. The 5 control functions allow the operation of numerous flight models. The mz-10 has Graupner HoTT technology, a very long range and a wide operating voltage range (up to 4.8 volts). Bright LEDs indicate the channels, the binding status and the model setting (4 types: normal, delta, v-tail or 2 ailerons). The mz-10 has 4 stick modes.The transmitter antenna is protected and integrated in the handle.The instructions in German, English, French and Italian are included. S1042.77

The Graupner mc-28 HoTT remote control is the model for the advanced model athlete. The mc-28 is suitable for almost all models. 16 control functions, 120 internal model memories, integrated telemetry and voice output as well as the fast and secure bi-directional transmission of Graupner HoTT 2.4 GHz technology make the mc-28 a true all-rounder.The mc-28 remote control has an internal circular polarized patch antenna with very high range and reliability.The temperature calibrated Hall sensor stick units also have excellent durability and reliability.Two large, high-contrast displays provide information on telemetry data and parameters at all times and enable fast and easy programming.The switches and buttons of the remote control can be freely assigned and thus individually adapted. 12 mixers are available for programming. 8 switching phase programs with announcement function can be adapted and named for each model.Thanks to the micro-SD card and micro USB interface, telemetry data and model memory can be imported and exported. Upgrades of the computer system are also carried out in an uncomplicated manner.Features:Microcomputer remote control system using the latest 2.4 GHz Graupner HoTT technologyCircularly polarized patch antennaTemperature calibrated billet units in the double ball bearing aluminium billet unitsvibration alarmsCharging via MicroUSB with LED charge indicatorModel types: model aircraft, helicopter, copter, vehicle, boatVoice output through switch operation or switching phase change with a choice of over 400 voice outputs and up to 40 user-definable voice outputsUp to 10 user definable alerts10 different vibration alarms for telemetry warnings, timer, RF signal, voltage alarmReturn channel speed for towing operation or camera chopper with several transmitters and receivers adjustable in the modelMusic player via programmable start/stop switchBidirectional communication between transmitter and receiverWireless L/S functiondifferent languages (German, English, French, Italian, Spanish) possible via software update. For availability of the corresponding language, see download area.Storage of telemetry data with date and timeServo cycle times for digital servos of 10ms selectable.Ultra-fast response times through direct and reliable data transmission from the main processor to the 2.4 GHz transceiver. No additional delays due to detours via a module processor.Operation and programming based on the proven concepts of the mc-32A high-contrast blue illuminated graphic display guarantees perfect control of the setting parameters such as model type, model memory, clocks and the operating voltage.16 control functionsFree assignment of all switches120 model memories10 switches/buttons, including two 3-step switches long, four 2-step switches, 2 buttons long, 2 buttons on the rear and 2 sliders as well as 2 lateral rotary encodersCAP-TOUCH control panels with key-lock function against unintentional operation.Numerous telemetry, programming and evaluation functions directly in the transmitter displayVoice output can be called up via freely programmable switchesExtensive programs for surface and helicopter modelsswash plate limiterSwitch "monitor" to control all switches and transmitter switches12 mixers, freely programmable for surface model and helicopter, each with freely selectable input and output functions, including 4 curve mixers with 5-point curve technology in 1 % steps, thus easily set and adjustable curve values for max. 5 points for throttle, pitch, tail or other non-linear travel. Using a sophisticated polynomial approximation method, the CPU calculates a real rounded ideal MPC (multi-point curve) mixer curve.8 switching phase programs with announcement function can be individually adapted and named for each model, the switching time can be programmed separately.SUPER SERVO menu with perfect overview of all servo setting data and simple parameter correction for 4 levels (direction of rotation, middle position, separate servo travel on both sides and separate travel limit for 16 servos with a total of 96 setting options)SUPER DUAL RATE, EXPO menu with 36 possible setting variants, for 3 servo functions and 6 flight phases.Practice-optimized multi-function menus for wing and helicopter models. Entering the number of aileron and flap servos automatically programs all necessary mixer functions in the multifunction area menu. Differential aileron mixer, butterfly mixer, dual-flap mixer, automatic gyro set function and other special functionsHelicopter swashplate mixers for 1-, 2-, 3- or 4-point linkage.Fail-safe monitor for 16 servo functionsComfortable clock menu. Stopwatch system, alarm timer, countdown timer, lap counter etc. 2 time and 1 lap/time value can be displayed.Stopwatch with history : In addition to the lap counter, there is a time 1 which records the switch-on times and a time 2 which records the switch-on and switch-off times separately.Transmitter operating time timer is automatically set to zero by the transmitter's battery charging process.Switch assignment of the flight phase switches: Now 6 switches, 2 of which have a priority function. The designation of each switch combination is freely selectable. This makes the number of flight phases independent of the number of flight phase switches. HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface S1033.77

The transmitter Graupner mc-26 HoTT is the model for the advanced model fans. The mc-26 is suitable for almost all models. 16 control functions, 120 internal model memories, integrated telemetry and voice output as well as the fast and reliable bi-directional transmission of the Graupner HoTT 2.4 GHz technology, it all makes themc-26 a true all- rounder.The mc-26 remote control has an internal circular polarized patch antenna with very high range and reliability.The control sticks, with double ball-bearing on each axle, ensure an optimal control feeling.Two large, high-contrast displays inform you about telemetry data and parameters at all times and enables fast and easy programming.The switches and buttons of the remote control can be freely assigned and thus individually adapted. 12 mixers are available for programming. 8 Switch phase programs with announcement function can be adapted and named for each model.Thanks to micro-SD card and micro USB interface, telemetry data and model memories can be imported and exported. Also upgrades of the firmware are carried out so uncomplicatedly.FeaturesMicrocomputer remote control set implemented with the very latest 2.4 GHz Graupner HoTT technologyRing limiter and channel sequencerBidirectional communicationbetween transmitter and receiverWireless T/P function6 different languages (German, English, French, Italian, Spanish and Dutch) available via software update. For the availability of a given language, go to the Download area.Storage of telemetry data with date and timeServo cycle times of 10 ms can be selected for digital servosUltra-fast response times through direct and reliable transmission of data from the main processor to the 2.4-GHz transceiver. No additional delays due to detours via a module processor.Operating and programming are similar to the proven concepts implemented in the mx-24A high-contrast, blue-illuminated graphic display ensures perfect control of parameter settings such as model type, model memory, timers and operating voltage.12 control functionsFree assignment of all switches120 model memories10 switches/keys, including two long 3-position switches, four 2-position switches, 2 long keys, 2 keys on the rear and 2 slider regulators as well as 2 side rotary controlsModes 1 to 4 freely selectableCAP TOUCH operating elements with key lock function to prevent unintentional operation.Numerous telemetry, programming and evaluation functions are presented directly on the transmitters screenVoice output can be called up via freely programmable switchesExtensive programs for fixed-wing and helicopter modelsSwashplate limiterMonitor switch to check all switches and control switches12 freely programmable mixers for wing or helicopter models, each with freely selectable input and output functions, including 4 curve mixers with 5-point curve technology in 1% increments, resulting in curve values that are easy to set and adjust at up to 5 points for throttle, pitch, tail or other non-linear actuations. The processor in the CPU employs an ingenious method of calculating polynomial approximations for truly-rounded, ideal MPC (multi-point curve) mixer curves.7 flight-phase programs can be individually adapted for each model and given a name. The switchover time is programmable separately.SUPER SERVO menu with a perfect overview of all servo setting data and simple parameter correction for 4 levels (direction of rotation, mid-point setting, separate servo travel on both sides and separate travel limiting on both sides for 12 servos with a total of 72 possible settings)SUPER-DUAL-RATE, EXPO menu with 36 possible settings for 3 servo functions and 6 flight phases.Highly practical multi-function menu for fixed-wing and helicopter models. Entry of the number of aileron and flap servos automatically programs all necessary mixer functions in the multi-function Wing mixers menu. Differential aileron mixer, butterfly mixer, dual-flap mixer, automatic gyro set function and other special functionsHelicopter swashplate mixer for 1, 2, 3, or 4-point steering.Fail-safe for 12 servo functionsConvenient timers menu. Stopwatch system, alarm timer, countdown timer, laps counter, etc. Two timers and one lap counter/timer can be displayed at the same time.Stopwatch with history: in addition to the lap counter there is a time 1 which captures the ON time and a time 2 which records the ON and OFF times separately.The transmitters operating time timer is automatically reset to zero by the battery charging process.Flight phase switch assignments: now 6 switches, 2 with priority function. Every switch combination can be named freely. This makes the number of flight phases independent of the number of flight phase switches.Linearising switchplate servos: electronic compensation for non-linear travel of swashplate rotary servos.Tail type normal, V-tail, Delta/flying-wing and 2 EL Sv 3+8 (which immediately makes 2 coupled elevator servos available without using free mixers or dual mixers)Flap count up to 4 AIL/4 FL: Full support of 8 wing servos, now even without use of free mixers.Flight phase switching delay, can be switched off: the delay time can be switched off for individual channels flight phase by flight phase (e.g. for motor off in electric models or to activate/deactivate helicopter head lock).16 phase namesFixed-wing mixer: New concept for the multi-flap menu to simplify settings of up to 8 wing servos on a flight-phase-specific basis in a comprehensible manner without requiring the use of free mixers.Number of flight phases: (fixed-wing: 7, helicopter: 6 + AR)Phase trimSwitchable Snap-Flap mixer EL => FL with a new offset function for easy course corrections and fast turns3 ring limiters for Voith-Schneider and similar drivesChannel sequencer for 3 channels for folding motors and landing gear doorsLogical switchesTrim memoryMulti-channel function to expand channels for up to 14 additional channelsMusic player and internal speaker for voice output and musicSwapping of servo assignment at receiver output on transmitter side and receiver sidePPM signal adjustable at the data outputModel memories of the mx-20 can also be loaded directly into the mc-20. To do so, simply copy the model memories on the PC to the appropriate directory. Then the switches and controls must be newly assigned because of the different hardware.CharacteristicsLinearization of swash plate servos : Electronic compensation of the non-linear path of swash plate.Tail configuration type normal, V tail, delta / flying wing, 2 ALE Sv 3 + 8 (two interconnected elevator servos are available immediately without the use of free mixers / crossmixers)Flap number up to 4 AILE / 4 FLAP: Full support of 8 wing servos, now also without the use of free mixers.Switch-off of the flight phase changeover delay: The deceleration time can be switched off for individual channels in the flight phase mode (eg for motor-off in the case of electric models or head-lock activation / deactivation for helis).16 phase namesWing mixer: Newly designed multi-flap menu for simplest settings of up to 8 wing servos in a flight-specific and clear manner even without the use of free mixers.Number of flight phases: (airplane: 8, Heli: 7 + AR)Phase trimmingSwitchable Snap Flap Mixer ELE -> FLAP with new offset function for easy course corrections and fast turning3 ring limiters for Voith-Schneider drives and similarChannel sequencer for 3 channels for folding propulsion and landing gear flapsLogic switchesTrim memoryMultichannel function channel expansion for up to 14 additional channelsMusic player and internal speaker for voice output and musicInterchangeable servo assignation on the receiver output from receiver side and transmitter sidePPM signal can be set at the data output HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface S1036.77

The mz-32 is centered around youThe Graupner mz-32 is our third generation telemetry radio system that advances RC radios to a level never seen before. With its rich set of hardware and software features, the mz-32 is introducing a new level of functionality where you, the user, can control almost any part of the radio.Be in control with the mz-32The mz-32 brings you the power to design your own screens, program your own control logic, filter your own voice notifications and even design the looks of your radio.Fly smoother and beyond with the mz-32The Graupner mz-32 is the first radio on the market that provides full 32 channel functions right out of the box! It supports five different model types such as electric, gas or turbine airplanes, helicopters, multirotor, cars and even boats.It can store and load up to 999 different user models, has 12 flight-phases and 16 curve mixers which can be set global or flight-phase dependent! The hall sensor 4096 resolution quad bearing gimbals provide the smoothest control feel a pilot can experience. The sealed gimbals can weather almost any field conditions and offer easy back-access for adjustment to fine-tune the stick tension the way you like.The mz-32 has a dual 2.4GHz redundant RF system driving a polarized patch antenna for unmatched signal quality and extended range. The included 9000mAh LiPo battery will provide more than 10 hours of operating time, which makes a long day at the field both possible and fun!The mz-32 adapts to youThe outdoor friendly 4.3-inch state of the art TFT color touchscreen ensures convenient access to all the mz-32 functions for setting up and managing your models.The highly optimized and fast performing graphical user interface is driven by a high-performance processor making access to menus and functions fast and crisp just like on your Smartphone. The intuitive touch and tap control makes navigation around the menus fast, easy and fun!The mz-32 is not only fast and responsive but is also fast to load. You will be using your mz-32 from power up in 10 seconds!Designing your own screen layouts to display information or create menu shortcuts can be done on the fly by simply tapping on the screen.The mz-32 provides over hundred widgets which make up the screens that you like and fit your style for controlling your models.You can create in total six screens that better fit your needs and personal style using the tip of your finger. No programming needed! You can do it all with the mz-32.One radio for all! German, English, French and Italian language is supported with more languages to come all in one radio!More channels more control for youWith 32 channels the mz-32 provides unlimited functionality and control over any model that you have. You can bind up to four 2.4GHz receivers so you can layout and distribute the channels the way you want.For example, you can have two six-channel receivers for each wing from where you can control ailerons, flaps, landing gear, and lights. Just supply main power to the wing, and you are ready to go.No complicated wiring or expensive hubs needed! This provides you with a level of simplicity with the benefits of RF redundancy unseen before in the industry.Still need more channels but do not have enough switches to do what you want? The mz-32 now also provides up to 64 digital switches that can be assigned and controlled from the widget menu with a simple tap. Create as many digital switch combinations as you like for turning lights and smoke on or off, turn cranes or water guns or anything else that you need to control without using up your switches.Switching and control options are further enhanced with Logical Switches (And, Or, Equal, Not), Control Switches, and Combination Switches. Each provides a new level of control to you depending on switch position or stick location.Voices you want to hearNeed to hear what is going on? The mz-32 provides endless options to generate almost any type of system or telemetry voice notification depending on the state of your radio such as switch positions, flight phase names, warnings, vario information and endless others.The mz-32 starts communicating with you from the moment you turn it on, informing you if a switch or control is in the wrong position for the selected model. No more surprises from collapsing landing gear, runaway motors or wrong gyro settings. The mz-32 can inform you when needed even when you forgot to bring down your landing gear or are about to run out of range or battery.Walks of shame are now a thing of the past!With over 600 installed voices and unlimited voice combinations, you can make almost any voice announcements or add as many as you want using our text to speech editor.Instant help where you need itIn need of help during setup or when something is unclear? Forget about searching through lengthy manuals or endless web searches! The mz-32 provides support right where you need. Each menu and option has its own context-sensitive answers right on the screen. Just tap the question mark and you will be instantly presented with help and assistance.Don’t like our help screens? Make or add your own help screens with whatever makes sense to you. The mz-32 is there for you allowing you to do and have the things you like the most.Connectivity that takes you furtherWith integrated Bluetooth and Wi-Fi the mz-32 is ready to connect you with the rest of the world! Use your Bluetooth headset to hear voice alerts or music from the built-in music player. It's your choice!Connect to your wireless LAN to receive notifications about newly released firmware that are instantly downloaded and installed on your radio. Your mz-32 is always up to date with the latest and greatest! The update can also be done by using the included USB cable and the latest firmware which you can always find on our website.Graupner takes connectivity further with a micro USB port that can charge your radio, access your included 16GB micro SD memory card where screens, models, voice files, music and screen shots are stored.You can use the USB or DSC port also as a joystick controller for games and flight simulators. Now you can practice flying your model on your favorite flight simulator with the same radio that you use at the field!The data port on the back can be configured to output a variety of digital signal outputs like SUMD, CROSSFIRE, Smart Box, and more. Adding and using third-party modules such as long-range FPV has never been easier than with the mz-32.All Graupner HoTT receivers now also support digital single wire output such as PPM, SUMD, and SBUS for more connectivity and better interoperability.The built-in file manager lets you manage things like voice files, screenshots, and more from wherever you are!Supported Protocols:HoTT-PCSmart-BoxExternal MonitorSUMDDSMX, DSM2 (Data Output)CROSSFIRE V1/V2Wireless controllers setupComputers, wirers, and programming boxes are things of the past! The mz-32 HoTT wireless protocol lets you do everything right on the radio! Need to set up your telemetry, flight controller or reverse the direction of your telemetry ESC or flight controller? Just use the shortcut key on the radio to access any of the receiver connected devices, and you are immediately in business. Do this at home while setting up your model or at the field to fine-tune your settings.Enjoy the HoTT integration of third-party flight controllers and sensors like Ikon, Spirit, 3Digi, MSH-Brain, SM Modelbau and many more for easy access using only your mz-32 radio. Each of Graupner's HoTT receivers provides this functionality, and there is no need to purchase anything else to use these convenient features.Train your buddiesTraining your family members or friends is as easy as bind and teach! The mz-32 provides a wireless and wired trainer support that can be used with any of our HoTT radios using the DSC port in the back.You can assign control to any of the active channels depending on your student's level and model capabilities. Passing control is easily done with a flick of a switch. S1024.77

Graupner AMIGO - a success story1960: AMIGO sees the light of day. With a wingspan of 1770 mm primarily as a free flight model, the model can also be controlled via remote control.1966: the legendary AMIGO II with the then proud wingspan of 2000 mm is released as a novelty. The design with the distinctive fuselage cross-section behind the trailing edge of the wing and the typical wing ears is legendary. AMIGO II remains in delivery at Graupner for 24 years.1990: From 1990 the AMIGO III with minor changes in detail, still manufactured in Kirchheim/Teck2011: With a new, fresh outfit comes 2011 the AMIGO IV in the Graupner Novelties Catalog. The parts are now laser cut and manufactured in Vietnam.2017: AMIGO V is delivered. The model is reminiscent of AMIGO II, as the wings, horizontal stabilizer and vertical stabilizer are AMIGO II. The new fuselage design is almost identical. Only the deep-drawn cockpit canopy has a modern shape and can be opened via a magnetic catch. Features:- Easy to assemble- Vacuum formed cockpit canopy- Laser-cut parts from balsa and plywood- Decoration set in the style of AMIGO II 9541

PEP does everything you wantThis small model is great fun to fly, gymnastics near the ground, sailing on a slope or climbing with the CAM FOLDING PROP in the thermals without a drive...PEP is always there and never overtaxes even inexperienced RC pilots. Due to its low wing loading and the coordinated drive, the basic speed is relatively low. The particularly good-natured stall behaviour also contributes to thewith pleasurable flies.Characteristics:Extremely low flying weight only approx. 365 gSuper climb with whispering soundSails in the thermals like a buzzardParticularly manoeuvrable and agileSimple construction, wing and tail unit made of full balsaRemovable wingEasy battery change due to flap in the fuselage bottomRC set perfectly matched to the model ( No. 4318.90) availableIncluded in the set:Clear building instructions in German with detailed illustrations.English, French and Italian available for download.Laser-cut balsa and plywood boards.Profile sawn end slats and ailerons made of balsa wood.Bowden cable for elevator.Fastening elements for engine and wing.Decal sheet with punched out lettering.Ready-to-use sanding block. 4318

The Vector Unit aircraft Leo and Emma are an excellent entry into the Vector Planes series and the hobby itself. The remote-controlled aircraft are made of special polypropylene foam (EPP). This foam is lightweight, flexible and sturdy. Crashed or bent, it bends back into the original shape by itself. By gently pressing, you can also post-mold it.The airplane flies self-stable. They may, but need not, be controlled. Just adjust the trim 3 clicks to the right, Leo and Emma then fly marvellous circles. The offspring will only have to operate the gas. In an emergency, the two of them will slide gently to the ground. Thus, Leo and Emma are suitable for little kids, too (but only under supervision). Vector Planes aircrafts are particularly suitable as an introduction to the Vector Planes series. The remote-controlled aircraft are made of EPP foam, are lightweight, flexible and yet robust. Crushed or bent, it bends itself back into its original shape. With gentle pressure, you can also reshape. The airplanes are flying stably. It may, but does not have to, be controlled. In an emergency, the two of them glide gently to the ground. Thus, Leo and Emma are also suitable for the very little ones (but only under supervision). 13301

This is O.S. "V" engine from this series. The FS-62 V engine has the nostalgic look of a 1930s aircraft engine. To complete the FS-62 V, a scale Jet Stream exhaust is included to give the authentic deep sound of a 4-stroke engine.Technical DataCooling: AirWidth [mm]: 51mmPower: 0,8 (1,1) kW (HP)Shaft thread: UNF 1/4-28Spacer holes lengthwise [mm]: 17,5mmCarburettor: 61TTotal weight [g]: 442gHeight approx. [mm]: 105.1mmMounting hole Ø [mm]: 3,7mmSpeed range approx.: 2400 - 11000 rpmBore [mm]: 25.0mmSpacing of transverse mounting holes [mm]: 44mmDisplacement [ccm]: 10.11 cm³Power kW (hp) at: 11000 rpmRecommended propeller: 12x6 - 14x6Length to hub: 102.8mmStroke [mm]: 20.6mmShaft Ø [mm]: 6.1mmBrand name: O.S.Range of application: Model aircraftincl. silencer: YesFuel: NitroVersion: 4-stroke NitroArticle number Manufacturer: OS30600 OS30600

Controls 8, 12 or 16 channelsWith the Graupner HoTT 2.4 GHz technology used, the Graupner GR-12L receiver features state-of-the-art components and software.Antenna diversity.The HoTT technology uses up to 75 channels. This ensures extreme operational reliability and insensitivity to external interference.Receiver voltage, temperature and signal strength are transmitted without additional sensors. Failsafe and Hold are programmable. The input sensitivity of the receiver and thus the range could be significantly increased.The small and extremely light receiver is used with SUMD, SBUS or SP2048 on Copter Flight Controls or Flybarless systems.The RSSI value can be output with SUMD, SBUS or SP2048 on channel 8, 12 or 16.3 additional solder terminals for K2-4 for servo pulse output or level output (0V or 3.3V max. 4mA) for switching LEDs or transistors.The GR-12L receiver has a wide voltage range from 3.6 V - 8.4 V (operable up to 2.5 V) for high reliability, even with voltage fluctuations.A red LED clearly indicates the operating status of the HoTT receiver at all times.In our Graupner online shop you will find the right accessories and spare parts for model making - the right remote controls, chargers, servos, NiMH and LiPo batteries.Hole spacing 20 mm x 20 mm. Hole diameter 3 mm.The sides can be easily removed so that the receiver has the dimensions 25 mm x 15 mm x 4 mm. Product FeaturesThe use of up to 75 channels ensures extreme operational reliability and is insensitive to external interference.Wide receiver voltage range from 3.6 V - 8.4 V (functional up to 2.5 V)The red LED indicates the operating statusThe size and the weight could be reducedThe receiver input sensitivity and thus the range has been further increased.Failsafe, Hold programmablefunctionstelemetry connectionSUMD signal for 8 channels for Copter Flight Controls (e.g. Betaflight and Raceflight) and Flybarless systems (e.g. for V-Stabi, Microbeast)Technical dataWidth [mm]: 25 (15) mmHeight [mm]: 4 mmTemperature range [°C]: -15...+70 °CAntenna length [mm]: 2x wire 145 (antenna 30) mmTotal weight [g]: 4 gfrequency: 2400...2483.5 MHzRange approx. [m]: ~3000 mLength [mm]: 25 mmDimensions [LxWxH in mm]: 25 x 25 (15) x 4 mmModulation: 2.4 GHz FHSS Current consumption [mA]: 70 mAOperating voltage [V]: 4...10 V Gyro: No Channels: 8 / 12 / 16 Telemetry capable: Yes Number of antennas: 2 S1045

With GRAUPNER HoTT 2.4 GHz technology, the 9-channel receiver has a new hopping telemetry transmission high-frequency section with state-of-the-art components and state-of-the-art software. A hardware antenna diversity for optimal reception. Without additional sensors, the receiver voltage, temperature and signal strength parameters are transmitted.With this receiver it is possible for the first time to control a multi-copter without using an external flight control. By eliminating the need for additional electronics and cables, weight can be saved and the remaining components can be tidied up.The integrated flight control is fully configurable via HoTT telemetry, which makes adjustment much easier. The system implements the control commands very accurately and precisely, which quickly gives you a familiar feeling of flying 'especially in FPV racing.Channel 5 can be used to switch between 2 flight modes. This can be used to switch to the self-neutralising position mode, which limits the inclination to about 50 degrees, or to the rotation rate mode (also called acro mode). In this case, there is no more angle limit and can be freely controlled via any axis, just like with a model helicopter.The simple controller teach-in function makes learning the controller paths child's play. Once activated, all ESCs can be controlled and taught-in directly with the gas stick.Maximum performance and stability is achieved by setting the roll sensitivity factor to the pitch sensitivity with unbalanced multi-headers. The gyro effect can also be adjusted depending on the gas, in order to still achieve high sensitivity with strong drives.The following multi-copter types are supported:Quadro X, Quadro +, Hexa V, Hexa I, Tri L, Tri RThis gyro receiver is used exclusively to control multicopters. The GR-18 (33579) is intended for use as a flybarless system or surface gyro. More characteristics:Very direct control feeling due to the elimination of the additional transmission path to flight controlSpace-saving, as the flight control and the necessary cables are omittedQuick and easy gyro assignmentSUMD output for external devicesTelemetry support for own HoTT sensors and HoTT sensors from other suppliersCan be programmed and operated with all HoTT transmitters available so that a laptop is no longer requiredMore technical data:Temperature range: - 15...+70 °CAntenna length: 2 x wire 145 (antenna 30) mmFrequency: 2400 ... 2483.5 MHzRange approx.: 4000 mModulation: 2.4 GHz FHSS Power consumption: 70 mAOperating voltage: (2,5) 3,6 ... 8,4 V S1019

Our most affordable 2.4GHz full range receiver with built-in telemetry, the Graupner GR-12L 6 Channel receiver is small sized and lightweight, lending itself very well for small park flyers, lightweight hand launch sailplanes, helicopters and multirotors. The ultra-low voltage requirements of the GR-12L allows it to operate on a single-cell LiPo making ideal for DLG gliders.The GR-12L provides real-time bi-directional data transmission of critical system health datalike temperatures, receiver voltage and signal strength using the Graupner HoTT protocol providing you with telemetry information you need for a safe and secure flight.FEATURES“ Up to 75 channel hopping for extreme operating reliability and immunity to external interference“ Compact and lightweight“ Front load servo connections for easier installation in small airframes“ Digital SUMD, SBUS signal output providing connectivity to other vendors flight controllers“ Selectable frame rate of 10ms or 20ms for digital or analog servos“ Fail Safe and Hold function“ Low power consumption“ Wide voltage ranges from 3.6V to 8.4V“ Built-in telemetry for temperatures, receiver voltage and receiver strength monitoringINCLUDESGR-12L ReceiverManual S1012

Power and simplicity are the hallmarks of the Graupner GR-18. Engineered with an integrated flight controller for multicopters, flybarless helicopters and an airplane 3-axis stabilization gyro, this is one of the most advanced 2.4 GHz receiver ever made by Graupner. The GR-18 is a long-range receiver using the Graupner HoTT protocol to provide real-time telemetry data of altitude, signal strength receiver voltage and temperature all to assist you during flight to enhance situational awareness and safety.Set up a multicopter, airplane or helicopter models, telemetry thresholds or flight controller settings easily and wirelessly using any Graupner HoTT radio transmitter: no computers or programming boxes necessary! Need to make a change to the PID or adjust the gyro? Simply land and make on-the-spot changes at the field or even in the air during flight! The GR-18 can be expanded with additional telemetry modules (GPS, OSD, ESC Telemetry, etc.) for continual improvement of your system’s reliability and performance.Features: Airplane Mode: three axes gyro stabilization with remote gain/deflection controlHelicopter Mode: Flybarless controller with remote gain controlMulticopter Mode: Quad X, Quad +, Hexa V, Hexa I, Tri L, Tri RUltra-fast gyros and accelerometer sensors for fast and crisp responseWireless setup of all controller features and functionsBuilt-in telemetry for altitude, signal strength, temperatures and receiver voltageUpgradable firmware using Graupner Firmware Update Studio 33579

Our smallest 2.4GHz receiver, the Graupner GR-12 SH+ is a micro, 6 Channel receiver. It is extremely lightweight – only 1.6 g – and its tiny footprint lends itself very well for small indoor flyers or micro flyer. The ultra-low voltage requirements – as low as 2.5 V – allows the GR-12 SH+ to operate on a single-cell LiPo battery making ideal for lightweight setups. This version, however, has an increased sensitivity input, increasing its operational range even further.The GR-12 SH+ can provide a digital SUMH signal on channel 6 as well as direct motor control of a brushed motor (Max 2A) on channel 1. Like all Graupner HoTT receivers the GR-12 SH+ provides telemetry data like temperatures, receiver voltage and signal strength, giving you the information you need for a safe and secure flight. Comes equipped with an SH connector.Features:Up to 75 channel hopping for extreme operating reliability and immunity to external interferenceExtremely compact and lightweightFive built-in programmable mixersWireless setup and access technologyFail Safe and Hold functionLow power consumptionReal-time wireless flight data recordingUltra-fast re-binding with HoTT radio Wide voltage ranges from 2.6V to 8.4VBuilt-in telemetry for temperatures, receiver voltage and receiver strength monitoringSUM digital signal output HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface 33565

Specially designed to work only with our X-8N and X-8E surface radios, the Graupner GR-8 is a 4 channel 2.4GHz receiver. Compatible with our new SUMD V2 technology, it supports Graupner’s exclusive HoTT telemetry protocols and can be programmed to output frame rates as low as 1.5ms for ultra-fast response time.Its compact size and top connector access makes the GR-8 well suited for any type of installation, especially where space is limited. The GR-8 HoTT receiver makes telemetry speed controllers and telemetry servos easy to install and is packed with standard features such as telemetry for signal strength, receiver voltage, temperature and main pack voltage (available with sensor, sold separately). With a range of up to 1000 meters and full spectrum utilization the GR-8 guarantees a reliable connection even at the most congested race tracks.Features:Up to 75 channel hopping for extreme operating reliability and immunity to external interferenceCompact and lightweightSupports SUMD V2 telemetry protocolFast frame rates as low as 1.5msWireless setupFail Safe and Hold functionLow power consumptionReal-time wireless telemetry data recordingUltra-fast re-binding with HoTT radio Wide voltage ranges from 2.6V to 8.4VBuilt-in telemetry for temperatures, receiver voltage and receiver strength monitoring 33504

The GR-12 is a 2.4GHz full range receiver with built-in telemetry, the Graupner GR-12 6 Channel receiver is small sized and lightweight, lending itself very well for small park flyers, lightweight hand launch sailplanes, helicopters and multirotors. The ultra-low voltage requirements of the GR-12 allows it to operate on a single-cell LiPo making ideal for DLG gliders.The GR-12 provides real-time bi-directional data transmission of critical system health data like temperatures, receiver voltage and signal strength using the Graupner HoTT protocol providing you with telemetry information you need for a safe and secure flight. The built-in program mixers allow increased flexibility in flight precision and function.Features:Up to 75 channel hopping for extreme operating reliability and immunity to external interferenceCompact and lightweightFront-load servo connections for easier installation in small airframesDigital output for SUMD, SUMDV3, SUMO, SUMI, SBUS signal providing connectivity to other vendors flight controllers and secondary satellite for other Graupner HoTT receiversSelectable frame rate of 10ms or 20ms for digital or analog servosFail Safe and Hold functionLow power consumptionWide voltage ranges from 3.6V to 8.4VBuilt-in telemetry for temperatures, receiver voltage and receiver strength monitoring5 built-in program mixers HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface 33506

The reliable and simple Graupner GR-32 offers redundancy without the complexity of installing multiple receiver satellites or additional hardware.With its 16 channels, dual receiver hardware and four antennas the GR-32 provides installation simplicity that is unmatched in the industry. With Graupner HoTT 2.4 GHz technology all real-time information regarding receiver voltage, receiver temperature and signal strength is always monitored and transmitted back to the radio without the need for additional sensors.The dual receiver has two complete and separate receiver sections as well as additional hardware antenna diversity. Signal quality is constantly monitored and automatically switched over to the better antenna signal, except during telemetry downlink transmissions in which the last antenna used for receiving is utilized. This ensures that the return channel data is transmitted via the better positioned antenna, assuring you that telemetry information is always available for a safe and secure flight.The receiver has a bus connector for additional telemetry sensors such as GPS, ESCs, Vario (and many others) to further enhance the value of your radio system providing pilots with valuable real-time information to improve flight operations.The Graupner GR-32 can be used in combination with digital flight controllers via output digital signals in SUMD, SBUS or SUMO single wire installations. The 6 separate battery inputs transform the GR-32 into an excellent power source for high-load servos eliminating the need for external power distribution systems.Features:Up to 75 channel hopping for extreme operating reliability and immunity to external interferenceBroad voltage ranges of 3.6 V - 8.4 V (functional to 2.5 V) ensures safe operation even during voltage fluctuationTwo LEDs to show operating statusSix power connectionsWireless setup and access technologyIncreased receiver input sensitivity providing a vertical range of up to 5000 metersEasy, front access servo connectionsFail-safe, hold, OFF and standard programmable directly from radio or receiver (channel 1: fail-safe; all others: hold)Programmable warning thresholds for low voltage, low or high temperaturesReal-time wireless flight data recordingUltra-fast re-binding with HoTT radio Digital output (SUMD, SUMDV3, SUMDIN, SUMO, SUMI, SBUS) at input or output connector for flight controllers like V-Stabi, Microbeast, Brain, Bavarian Demone, 3Digi, Naze, et alSUM signal at input or output connector for flight controllers like V-Stabi, Microbeast, Naze, et alSelectable frame rates between 10ms to 20msCompact and lightweight 33516

Reliable communication with Graupner HoTT radios is no issue for the Graupner GR-24 12ch 2.4 GHz receiver, suitable for any type of application including large scale warbirds and large scale sailplanes. You will benefit from constant, real-time information monitoring of receiver voltage, receiver temperature and signal strength that is transmitted back to the radio without the need for additional sensors.The dual, full range 2.4 GHz diversity antenna system continually hops to the better antenna signal, utilizing the last antenna used for receiving telemetry downlink transmissions. This ensures that the return channel data is transmitted via the better positioned antenna, assuring you that telemetry information is always available for a safe and secure flight.FeaturesUp to 75 channel hopping for extreme operating reliability and immunity to external interferenceBroad voltage ranges of 3.6 V - 8.4 V (functional to 2.5 V) ensures safe operation even during voltage fluctuationDual power connectionsWireless setup and access technologyLED to show operating statusIncreased receiver input sensitivity providing a vertical range of up to 4000 metersEasy, front access servo connectionsFail-safe, hold, OFF and standard programmable directly from radio or receiver (channel 1: fail-safe; all others: hold)Programmable warning thresholds for low voltage, low or high temperaturesReal-time wireless flight data recordingUltra-fast re-binding with HoTT radio Digital output (SUMD, SUMDV3, SUMDIN, SUMO, SUMI, SBUS) at input or output connector for flight controllers like V-Stabi, Microbeast, Brain, Bavarian Demone, 3Digi, Naze, et alSelectable frame rates between 10ms to 20ms.Compact and lightweight HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface 33512

Reliable communication with Graupner HoTT radios is no issue for the Graupner GR-16 8ch 2.4 GHz receiver, suitable for any type of application including 3D airplanes, pattern planes, full house electric gliders and sport flyers. You will benefit from constant, real-time information monitoring of receiver voltage, receiver temperature and signal strength that is transmitted back to the radio without the need for additional sensors.The dual, full range 2.4 GHz diversity antenna system continually hops to the better antenna signal, utilizing the last antenna used for receiving telemetry downlink transmissions. This ensures that the return channel data is transmitted via the better positioned antenna, assuring you that telemetry information is always available for a safe and secure flight.Features:Up to 75 channel hopping for extreme operating reliability and immunity to external interferenceBroad voltage ranges of 3.6 V - 8.4 V (functional to 2.5 V) ensures safe operation even during voltage fluctuationDual power connectionsWireless setup and access technologyLED to show operating statusIncreased receiver input sensitivity providing a vertical range of up to 4000 metersEasy, front access servo connectionsFail-safe, hold, OFF and standard programmable directly from radio or receiver (channel 1: fail-safe; all others: hold)Programmable warning thresholds for low voltage, low or high temperaturesReal-time wireless flight data recordingUltra-fast re-binding with HoTT radio Digital output (SUMD, SUMDV3, SUMDIN, SUMO, SUMI, SBUS) at input or output connector for flight controllers like V-Stabi, Microbeast, Brain, Bavarian Demon, 3Digi, Naze, et alSelectable frame rates between 10ms to 20msCompact and lightweight HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface 33508

With the Falcon 12 plus Graupner presents a powerful 6-channel receiver with integrated 3-axis gyro and 3-axis acceleration sensor (A-meter) and diversity antenna.With the GRAUPNER HoTT 2.4GHz technology, the receiver has a secure hopping telemetry transmission high-frequency part with high-quality components and state-of-the-art software. The receiver transmits the parameters "receiver voltage", "receiver temperature" and "signal strength" to the transmitter without additional sensors.The new antenna amplifier together with the antenna diversity provides an enormous range. The faster 32-bit L4 processor is a guarantor for power-saving operation and the higher performance ensures that the Falcon 12 plus can also be used as a flybarless system for helicopters and as a flight controller for copters.Of course the integrated Falcon gyro system can also be used perfectly for wing models. There are different gyro modes: OFF, normal stabilization, heading lock and turn rate mode which provides for particularly easy knife flight and easy torquing and supports the pilot. Extremely fast, easy and comfortable adjustment via the hot transmitter telemetry menu.Just like its namesake, the Falcon, the Falcon 12 embodies determination, power and precision. Go on the hunt for the perfect flight with the Falcon.Surface modelsStabilization of the flight model in difficult wind conditions for up to 3 axesNatural flight behaviour due to proportional gyroscope suppressionDue to the 3-axis gyroscope, even difficult to control aerobatic models can be flown very well and aerobatics are extremely simplifiedFlight figures can be flown much cleaner3 different gyro modes: OFF, normal stabilization, heading lock and turn rate mode for easy knife flight and easy torquingEasy setting of the gyro assignmentSetting the parameters via HoTT telemetrySoftware with attitude mode for HoTTrigger 1400 and V-Venture available, allows easy landings even in difficult wind conditionsFlybarless system for helicoptersBasic setting completed in a few minutesFast and innovative axle assignment, thus flexible installation directionExtremely space-saving due to size, weight and omission of cables, therefore easy to storeEspecially vibration insensitive 3 axis sensors of the latest generationPirouette optimization of the swashplate and direction of the tail torque compensation are detected automaticallyAll common helicopter swashplates 90/120/135/140 degreesAdjustable swashplate rotation up to 90 degrees for multi-blade headsClearly arranged standard and, if required, selectable expert menuSensitivity Parameters during flight can be adjusted to speed and style, also depending on flight phase via encoderSuper fast by eliminating the transmission time from the receiver to the flybarless systemVery direct steering feelFlight Control for CopterThe Copter software Q06 is installed on the receiver by a software updateBasic settings made in a few minutes via the telemetry menuFast and innovative axle assignment, thus flexible installation directionEspecially vibration insensitive 3 axis sensors of the latest generationThe housing protects the electronics in case of crashes. The special double-sided adhesive tape additionally dampens the vibrations.8kHz gyro frequency, multishot and fast PID control routines as well as new software filters ensure a perfect flying experience.Also new is the Quadro Type XI (Quadrocopter X with reverse prop rotation), which has proven itself especially in FPV races, to keep the lens clear and turn the props away from the obstruction.When connecting the GPS sensor S8437 to K5/telemetry and setting K5 to SENSOR, the functions are additionally available: GPS hold with altitude hold, come home and fly waypoints (with HoTT Viewer 2 App and USB-OTG cable).Telemetry support of own Hott Sensors and Hott Sensors of other suppliersSUMD output for other flybarless receivers.Voltage input for external voltage divider, e.g. already included in controllers S3082 and S3083.HV suitable. Input voltage range 3.6...12.6 VCan be programmed and operated with all previously available HoTT transmitters with telemetryFlybarless for helicoptersEasy programming of the basic settings via telemetry.The pirouette optimization is automatically determined from the parameters and works extremely well.Extreme flight stability with full 3D capability even with the basic settings.Effect for tail and swashplate easily adjustable via the telemetry menu or via selectable sensors.Further optimization possibilities in expert mode for the personal flight style and personal needs.Extremely simple adjustment of the basic settings via telemetry:Rotor rotation directionSwashplate typeSwashplate frequency 50...200 HzSwash plate directionSwashplates Servo centers Servo 1...3Set swashplate cyclical travel to 8Swashplates Pitch travel A/BSwashplate limitSwashplate rotationTail servo center pulse 760µs, 960µs, 1.5 msTail servo frequency 50...333 HzTail servo center positionExpo yes/noLogging for service purposesExpert mode yes/noSimple gyro axis assignmentGyro action for tail and swashplate via telemetry or adjustable transducers.In expert mode further parameters can be set. S1034

The Graupner Falcon 12 sets a new standard for flight controllers. The Falcon 12 is an airplane stabilizer, flybarless helicopter controller and multirotor controller all in one compact package that includes also real-time telemetry and a long-range receiver.Setting up the Falcon 12 is easy. By using the wireless connection on your HoTT radio you can access all the features and settings of the Falcon 12 without the need for cables or computers. Controller settings can be adjusted during flight or changed using flight modes. The Falcon 12 can adapt itself to your needs or flying style making it the most versatile flight controller on the market.The Falcon 12 flight controller can be used in almost any airplane, helicopter or multirotor application accommodating many type of configurations and settingsThe Falcon 12 can be expanded with additional telemetry modules (GPS, Altimeter, ESC Telemetry and more)Features:Airplane Mode - Three axes airplane multi-mode stabilization OFF/Normal/Heading Lock/Rate/Stabilization & RecoveryHelicopter Mode - Flybarless controllerMultirotor Mode - All quad type configurationsModes and rates can be changed during flightSUMD 8ch output for third party controllersNew ultra-fast gyro sensors for fast and crisp responseNew long range single wire antenna receiverNew auto binding modeSmall form factor that fits in any small sized air frameSetup made easy using wireless connection with Graupner HoTT radioSupports V-Tail, Dual Elevators, Butterfly, Flaperon mixingBuilt in five channel mixerReal-time wireless flight data recordingBuilt in telemetry for signal strength, temperatures and receiver voltageFree firmware updates using the Graupner Firmware Update Studio S1035

GR-24 PRO 12CH Airplane Helicopter Multirotor Gyro Telemetry ReceiverPower and simplicity are the hallmarks of the Graupner GR-24 PRO. Engineered with an integrated flight controller for multicopters, FBL helicopters and an airplane 3-axis stabilization gyro, this is the most advanced 2.4 GHz receiver ever made by Graupner. The GR-24 PRO is a long-range receiver using the Graupner HoTT protocol to provide real-time telemetry data of altitude, signal strength receiver voltage and temperature all to assist you during flight to enhance situational awareness and safety.Set up a multicopter, airplane or helicopter models, telemetry thresholds or flight controller settings easily and wirelessly using any Graupner HoTT radio transmitter: no computers or programming boxes necessary! Need to make a change to the PID or adjust the gyro? Simply land and make on-the-spot changes at the field or even in the air during flight! The GR-24 PRO can be expanded with additional telemetry modules (GPS, OSD, ESC Telemetry, etc.) for continual improvement of your system’s reliability and performance.FEATURES“ Airplane Mode: 3-axis gyro stabilization with wireless gain/deflection control“ Helicopter Mode: Flybarless controller with wireless PID and gain control“ Multicopter Mode: Quad X, Quad +, Hexa V, Hexa I, Tri L, Tri R, OCTO, Acro 3D“ Multicopter Control: Attitude/Rate Mode, Auto Flip Mode“ Ultra-fast gyros and accelerometer sensors for fast and crisp response“ Wireless setup of all controller features and functions“ Real-time wireless flight data recording“ Built-in telemetry for altitude, signal strength, temperatures and receiver voltage“ Free firmware updating using Graupner Firmware Update StudioINCLUDES“ GR-24 PRO 3XG+3A+3M VARIO Receiver“ Manual 33583

Description receiver GR-12 + 3xG HoTT from GaupnerWith the GRAUPNER HoTT 2.4 GHz technology, the receiver has a new Hopping Telemetry Transmission high-frequency section with the latest components and state-of-the-art software. The receiver voltage and temperature parameters, as well as the signal strength, are transmitted without additional sensors. 3-axis gyro:Stabilization of the flight model under difficult wind conditions for up to 3 axesNatural flight behaviour due to proportional gyroscope suppressionVery good stabilisation for cleanly flown manoeuvres With the 3-axis gyroscope, even difficult to control aerobatic models can be flown very well and aerobatic flying is extremely simplified.flight figures can be flown much cleanerSimple gyro assignment settingsetting the parameters via HoTT telemetrySpecification:Dimensions (LxWxH) 36 x 21 x 10 mmOperating voltage (2,5) 3,6 ... 8,4 VFrequency 2400 ... 2483.5 MHzAll-up weight, approx. 7 gModulation 2.4 GHz FHSSRange approx. 2000 mCharging rate 70 mATemperature range -15 ... +70 °CAerial length 1 x Draht 145 (Antenne 30) mm 33576

The Graupner GR-12 Gyro Vario telemetry receiver features an integrated 3-axis stabilization system and altimeter to make it easier for fixed wing pilots to control their airplanes under different flying conditions.With integrated telemetry, the GR-12 is easy to setup using only your Graupner radio to access all stabilization functions without the need for cables or computers. Sailplane or DLG pilots will especially appreciate the built in VARIO to assist during thermal flight and altitude readings.The GR-12 Gyro Vario receiver can be used in almost any airplane, sport, 3D, aerobatic as well as sailplanes. The GR-12 also provides internal mixers to accommodate different type of wing configurations such as V-Tail, dual elevators and butterfly.The GR-12 Vario gyro receiver can be expanded with additional telemetry modules (GPS, Altimeter, ESC Telemetry)Features:3-axes airplane stabilizationMulti-mode stabilization OFF/Normal/Heading Lock/RateBuilt in altimeter and varioModes and rates can be changed during flightUltra-fast gyro sensors for fast and crisp responseSetup made easy using your Graupner radioSupports V-Tail, Dual Elevators, Butterfly, Flaperon mixingReal-time wireless flight data recordingBuilt in telemetry for signal strength, temperatures and receiver voltageFree firmware upgrades using Graupner Firmware Update Studio 33577

Compatible with all our HoTT 2.4 GHz telemetry radios, the Graupner GR-4 HoTT is a 2 channel receiver with bi-directional data transmission for real-time information regarding system health and performance precision and function.Its compact size and top connector access makes the GR-4 well suited for any type of installation, especially where space is limited. The GR-4 HoTT receiver is packed with standard features such as telemetry for signal strength, receiver voltage, temperature and main pack voltage (available with sensor, sold separately). With a range of up to 500 meters and full spectrum utilization the GR-4 guarantees a reliable connection even at the most congested race tracks.Features:Up to 75 channel hopping for extreme operating reliability and immunity to external interferenceCompact and lightweightWireless setupFail Safe and Hold functionLow power consumptionReal-time wireless telemetry data recordingUltra-fast re-binding with HoTT radio Wide voltage ranges from 2.6V to 8.4VBuilt-in telemetry for temperatures, receiver voltage and receiver strength monitoringTechnical datawidth: 21 mmHeight approx.: 15 mmTemperature range: -15...70 °CAntenna length: 1 x wire 145 (antenna 30) mmTotal weight approx.: 6 gFrequency: 2400... 2483.5 MHzRange approx.: 500 mLength approx.: 30 mmDimensions approx.: 30 x 21 x 15 mmModulation: 2.4 GHz FHSSPower consumption: 35 mAOperating voltage: (2,5) 3,6 ... 8,4 VChannels: 2number of antennas: 1 33502
